Sanyo PLC-WU3800 Service Manual

KY7-WU380000
-80-
Key No. Part No. Description Key No. Part No. Description
Mechanical Parts List
PACKING MATERIALS
610 357 0297 CARTON CASE-KY7AF
610 354 7756 POLY BAG 0440*0480*NC
610 336 8221 CUSHION SPACER -KB3AC
610 339 5463 CUSHION-KB3AC
655 002 4824 INSTALLATION SHEET KF3AC
ACCESSORIES
OWNER’S MANUAL
610 356 9505 CD-ROM,OWNERS MANUAL-KY7AF
655 004 9667 SETUP INST-KY7AF
REMOTE CONTROL
645 099 3190 ASSY,REMOCON MXAC
610 344 9944 RC-BATTERY LID-MXAC
AC CORD
! US 945 064 6363 CORD,POWER-3.0MK,US
! EU 945 054 1156 CORD,POWER-3.0MK
! HK 945 054 1149 CORD,POWER-3.138MK
!BRA 645 102 6996 CORD,POWER_2.5MK,BRA
MISCELLANEOUS
610 338 0223 STRAP CAP-KB3AC
610 356 0205 CARRY BAG-KA2AC
945 073 4855 CABLE,INTERFACE VGA
645 093 1642 CABLE,INTERFACE VGA
645 104 2705 CABLE,INTERFACE VGA
652 002 9552 CABLE,INTERFACE VGA
CABINET PARTS
C01 610 331 6413 ASSY,STAND LEG-KM6A
C02 610 345 9158 BUTTON-KY7AC
C03 610 357 6169 CABINET TOP-KY7AF
C04 610 347 5448 CABINET FRONT-KB8AC
C05 610 338 4115 CABINET BTM-KF3AC
610 345 3965 CABINET BTM-KF3AC
C06 610 336 2434 CAP LENS-KB3AC
C07 610 333 8798 COVER LP SERVICE-KM6AC
C08 610 338 3682 FILTER BASE-KF3AC
C09 610 333 9207 DEC INLAY LED-KL6AC
C10 910 325 2477 DEC LEG-PT5EC
C11 910 302 5613 DEC SHEET-M4JA
C12 610 333 9290 FILTER BASE-KM6AC
C13 610 345 9141 GRILLE-KY7AC
C14 945 047 8032 BADGE,SANYO*26.2X5.7L26.0
C15 610 357 0310 DEC AV SHEET-KY7AF
C16 610 347 0542 SPACER SHEET LENS-KY7AC
610 336 6647 SPACER SHEET LENS-KB3AC
CHASSIS PARTS
M01 610 334 0128 SPACER SHEET TRIGGER-KM6AC
M02 610 334 4348 HOLDER POWER PWB BTM-KM6AC
M03 610 334 5895 HOLDER T SW-KM6AC
M04 610 344 6837 MOUNTING MCI-KY7AC
M05 610 338 3613 MOUNTING DUCT BTM-KF3AC
M06 610 338 3675 MOUNTING DUCT TOP-KF3AC
M07 610 334 4386 MOUNTING DUCT LP-KM6AC
M08 610 344 6820 PANEL AV- KY7AC
M09 610 334 0067 SPACER SHEET#POWER T-KM6AC
M10 610 334 7097 SPACER SHEET#POW T TOP-KM6AC
610 343 0348 SPACER SHEET#POW T TOP-KM6AC
M11 610 331 1692 OPTICAL BASE BTM-KM6A
M12 610 331 1715 OPTICAL BASE TOP A-KM6A
M13 610 331 1722 OPTICAL BASE TOP B-KM6A
M14 610 333 9986 SPACER SHEET LP BK-KM6AC
SCREWS
S01 411 179 8801 SCR S-TPG BIN 3X10
S02 411 077 8606 SCR TPG FLT 3X8
S03 411 189 6507 BOLT HEX-SCT+SW+W 2.5X5
S04 312 070 3400 SPECIAL SCREW-3.0X10V
S05 312 069 7105 SPECIAL SCREW V
S06 411 189 7207 SCR S-TPG BIN 3X8
OPTICAL PARTS
L01 610 347 4588 ASSY,PNL/PSM-KY7AC
(Including Key No.L01-1R to L01-2B AND LCD Panel)
L01-1R 645 095 4221 POLARIZED GLASS(OUT/R)
L01-1G 645 101 1428 POLARIZED GLASS(OUT/G)
L01-1B 645 089 3520 POLARIZED GLASS(OUT/B)
L01-2G 645 101 1411 PRE-POLARIZED GLASS(OUT/G
L01-2B 645 097 3918 PREPOLARIZED GLASS(OUT/B)
L02-R 645 089 3476 POLARIZED GLASS(IN/R)
L02-G 645 105 0458 POLARIZED GLASS(IN/G)
L02-B 645 089 3490 POLARIZED GLASS(IN/B)
L03 645 092 9892 PRISM(PBS)
L04 645 093 1451 LENS,PROJECTION
645 101 0490 LENS,PROJECTION
645 102 1762 LENS,PROJECTION
L05 645 093 4681 LENS,INTEGRATOR(IN)
L06 645 093 4698 LENS,INTEGRATOR(OUT)
L07 945 088 7827 LENS,CONDENSER(OUT)
L08 945 088 7834 LENS,CONDENSER(G)
L09 945 088 7841 LENS,CONDENSER(B)
L10 945 088 7858 LENS,CONDENSER(R)
L11 945 088 7865 LENS,RELAY(IN)
L12 945 088 7872 LENS,RELAY(OUT)
L13 945 088 7889 MIRROR(B)
L14 945 088 7896 MIRROR(R)
Note: Parts order must contain Chassis No., Part No., and Descriptions.

Sanyo PLC-WU3800 Specifications

General

Matrix size	0.59 \
Projection distance	0.99 - 12.1 m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	40 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	±40 °
Audio input	2
Aspect ratio	16:10
Network ready	Yes
Power supply type	AC
Dimensions (WxDxH)	335.7 x 257.5 x 93.6 mm
Connectivity technology	Wired
Focus	Manual
Digital zoom	16 x
Focal length range	19.2 - 30.2 mm
Noise level	35 dB
Noise level (economic mode)	31 dB
Dot clock scanning frequency	140 MHz
Lamp type	NSHA
Lamp power	275 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	3000 h
DVI port	No
Composite video in	-
Serial interface type	RS-232
USB 2.0 ports quantity	0
Supported video modes	1080i, 1080p, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	White
AC input voltage	100 - 240 V
Power consumption (standby)	0.7 W
Power consumption (typical)	317 W
Power consumption (PowerSave)	280 W
Cables included	VGA

Weight and Dimensions

Depth	257.5 mm
Width	335.7 mm
Height	93.6 mm
Weight	3500 g
