Sanyo PLC-WU3800 Service Manual

-23-
 ●: Adjustment necessary ❍: Check necessary
Adjustments after Parts Replacement
Adjustments
Disassembly / Replaced Parts
LCD/
Prism Ass’y
Integrator
Lens (OUT)
Relay
Lens (OUT)
Polarized Glass
Power Board Main Board
R G B
Optical Adjustments
Contrast Adjustment
R-Contrast adjustment
❍
●
G-Contrast adjustment
❍ ●
B-Contrast adjustment
❍ ●
Integrator lens adjustment
❍ ●
Relay lens-out adjustment
❍ ●
Electrical Adjustments
Fan Voltage adjustment
● ●
Center voltage adjustment
●
Black-black voltage adjustment
●
Panel type check and setting
● ●
Auto calibration adjustment [PC]
❍
Auto calibration adjustment
[Component]
❍
Auto calibration adjustment
[Video]
❍
Common Voltage adjustment
● ●
50% white adjustment [PC]
● ●
White balance adjustment [PC]
❍ ❍
50% white adjustment [Video]
● ●
White balance adjustment
[Video]
❍ ❍
Keystone offset adjustment
●
Color shading correction adjust-
ment*
❍ ❍ ❍ ❍ ❍
*To adjust this item,the Projector Service Tool v.4.20 software is needed.Refer to the ownew's manual
for this software for the furter details.

Sanyo PLC-WU3800 Specifications

General

Matrix size	0.59 \
Projection distance	0.99 - 12.1 m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	40 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	±40 °
Audio input	2
Aspect ratio	16:10
Network ready	Yes
Power supply type	AC
Dimensions (WxDxH)	335.7 x 257.5 x 93.6 mm
Connectivity technology	Wired
Focus	Manual
Digital zoom	16 x
Focal length range	19.2 - 30.2 mm
Noise level	35 dB
Noise level (economic mode)	31 dB
Dot clock scanning frequency	140 MHz
Lamp type	NSHA
Lamp power	275 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	3000 h
DVI port	No
Composite video in	-
Serial interface type	RS-232
USB 2.0 ports quantity	0
Supported video modes	1080i, 1080p, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	White
AC input voltage	100 - 240 V
Power consumption (standby)	0.7 W
Power consumption (typical)	317 W
Power consumption (PowerSave)	280 W
Cables included	VGA

Weight and Dimensions

Depth	257.5 mm
Width	335.7 mm
Height	93.6 mm
Weight	3500 g
