KY7-WU380000
-79-
Parts Location Diagrams
527
528
L14
L10
L03
L15
L07
L16
L13
L09
L06
L08
In the Optical Unit
L11
L14
CAUTION:
Part must be placed in specified direction when replacing the optical parts.Please see"Optical parts disassembly" for
further instructions.
