-73-
IC Block Diagrams
● MP2307 <DC-DC Converter, IC5842, IC5860>
● LC87F2G08A <Sub CPU, IC6002>
Insert Interrupt
Stand-by Interrupt
Reset Circuit
Reset Interrupt
Clcok Generator
Bass Interface
Port 0
Timer 0
Timer 1
Timer 6
Timer 7
Base Timer
Port 1
Port 2
Port 7
INT3(Noise remove)
Port 2
Flash ROM
B Resistor
C Resistor
Stack Pointer
On Chip Debug
