Sanyo PLC-WU3800 User Manual

75
Appendix
ON-SCREEN
DISPLAY
RESOLUTION
H-Freq.
(KHz)
V-Freq.
(Hz)
D-VGA 640 x 480 31.47 59.94
D-SVGA 800 x 600 37.879 60.32
D-WXGA 1 1366 x 768 48.36 60.00
ON-SCREEN
DISPLAY
RESOLUTION
H-Freq.
(KHz)
V-Freq.
(Hz)
D-1035i 1920 x 1035
D-1080i 1920 x 1080
D-1080i 1920 x 1080
33.75
60.00
(Interlace)
33.75
60.00
(Interlace)
28.125
50.00
(Interlace)
D-XGA 1024 x 768 43.363 60.00
D-WXGA 2 1360 x 768 47.7 60.00
D-WXGA 3 1376 x 768 48.36 60.00
P
Note:
• Depending on your PC settings, the digital signals of your PC may not be projected correctly. In such a case,
confirm your PC settings.
• When you project a DVI signal, connect the cables, turn the projector on, then select the input. Finally, turn
on your PC. Be sure to follow this procedure, otherwise an image may not be projected on the screen. If an
image is not projected correctly, restart your PC.
• Do not disconnect the cable while the projector is running. If the cable has been disconnected and then
reconnected, an image may not be correctly projected.
• The specifications are subject to change without notice.
D-WXGA 4 1360 x 768 56.160 72.000
D-WXGA 5 1366 x 768 46.500 50.000
D-WXGA 6 1280 x 768 47.776 59.870
D-WXGA 7 1280 x 768 60.289 74.893
D-SXGA1 1280 x 1024 63.98 60.02
D-SXGA2 1280 x 1024 60.276 58.069
D-SXGA3 1280 x 1024 31.65 29.80
D-WXGA 8 1280 x 768 68.633 84.837
D-WXGA 9 1280 x 800 49.572 59.870
D-WXGA 10 1280 x 800 41.200 50.000
D-WXGA 11 1280 x 800 49.702 59.810
D-SXGA+ 1 1400 x 1050 63.97 60.19
D-SXGA+ 2 1400 x 1050 65.350 60.120
D-SXGA+ 3 1400 x 1050 65.120 59.900
D-WSXGA +1
1680 x 1050 65.290 59.954
D-UXGA 1600 x 1200 75.000 60.000
D-WUXGA 2 1920 x 1200 74.038 59.95
When the input signal is digital from HDMI terminal, refer to the chart below.
D-WXGA +1
1440 x 900 55.935 59.887
D-480p 640 x 480 31.47 59.88
D-575p 768 x 575 31.25 50.00
D-720p 1280 x 720 37.50 50.00
D-720p 1280 x 720 45.00 60.00
D-1080i 1920 x 1080 ----
D-1080p 1920 x 1080 ---- 59.94
D-1080p 1920 x 1080 ----
60.00
D-1080p 1920 x 1080 ---- 50.00
59.94
(Interlace)
D-WXGA 12 1280 x 800 63.980 60.020

Sanyo PLC-WU3800 Specifications

General

Matrix size	0.59 \
Projection distance	0.99 - 12.1 m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	40 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	±40 °
Audio input	2
Aspect ratio	16:10
Network ready	Yes
Power supply type	AC
Dimensions (WxDxH)	335.7 x 257.5 x 93.6 mm
Connectivity technology	Wired
Focus	Manual
Digital zoom	16 x
Focal length range	19.2 - 30.2 mm
Noise level	35 dB
Noise level (economic mode)	31 dB
Dot clock scanning frequency	140 MHz
Lamp type	NSHA
Lamp power	275 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	3000 h
DVI port	No
Composite video in	-
Serial interface type	RS-232
USB 2.0 ports quantity	0
Supported video modes	1080i, 1080p, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	White
AC input voltage	100 - 240 V
Power consumption (standby)	0.7 W
Power consumption (typical)	317 W
Power consumption (PowerSave)	280 W
Cables included	VGA

Weight and Dimensions

Depth	257.5 mm
Width	335.7 mm
Height	93.6 mm
Weight	3500 g
