Sanyo PLC-WU3800 User Manual

3
Table of Contents
Trademarks
Each name of corporations or products in this book is either a registered trademark or a trademark of its respective
corporation.
Features and Design . . . . . . . . . . . . . . . . . . .2
Table of Contents . . . . . . . . . . . . . . . . . . . . . .3
To the Owner. . . . . . . . . . . . . . . . . . . . . . . . . .4
Safety Instructions . . . . . . . . . . . . . . . . . . . . .5
Air Circulation 6
Moving the Projector 6
Installing the Projector in Proper Directions 7
Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Part Names and Functions . . . . . . . . . . . . . .9
Front 9
Back 9
Bottom 9
Rear Terminal 10
Top Control 11
Remote Control 12
Remote Control Battery Installation 13
Remote Control Operating Range 13
Remote Control Code 13
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . .14
Positioning the Projector 14
Adjustable Feet 14
Connecting to a Computer 15
Connecting to Video Equipment 16
Connecting to Component Video Equipment 17
Connecting the AC Power Cord 18
Basic Operation . . . . . . . . . . . . . . . . . . . . . .19
Turning On the Projector 19
Turning Off the Projector 21
How to Operate the On-Screen Menu 22
Main Menu 23
Zoom and Focus Adjustment 24
Auto Setup Function 24
Keystone Correction 24
Sound Adjustment 25
Remote Control Operation 26
Computer Input . . . . . . . . . . . . . . . . . . . . . .28
Input Source Selection (Computer 1:
RGB / Component / RGB(Scart) ) 28
Input Source Selection (Computer 2: RGB) 29
Computer System Selection 30
Auto PC adjustment 31
Manual PC adjustment 32
Image Mode Selection 34
Image Adjustment 35
Screen Size Adjustment 36
Video Input . . . . . . . . . . . . . . . . . . . . . . . . . .38
Input Source Selection (Video, S-video) 38
Input Source Selection (Component,
RGB Scart 21-pin, HDMI) 39
Video System Selection 40
Image Mode Selection 41
Image Adjustment 42
Screen Size Adjustment 44
Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Setting 45
Information . . . . . . . . . . . . . . . . . . . . . . . . . .61
Input Source Information Display 61
Maintenance and Cleaning . . . . . . . . . . . . .62
WARNING indicator 62
Cleaning the Filters 63
Resetting the Filter Counter 63
Attaching the Lens Cap 64
Cleaning the Projection Lens 64
Cleaning the Projector Cabinet 64
Lamp Replacement 65
Resetting the Lamp Counter 66
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Troubleshooting 67
Menu Tree 71
Indicators and Projector Condition 73
Compatible Computer Specifications 74
List of Picture in Picture 76
Technical Specifications 77
Optional Parts 78
PJ Link Notice 79
Configurations of Terminals 80
PIN Code Number Memo 81
Dimensions 82

Sanyo PLC-WU3800 Specifications

General

Matrix size	0.59 \
Projection distance	0.99 - 12.1 m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	40 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	±40 °
Audio input	2
Aspect ratio	16:10
Network ready	Yes
Power supply type	AC
Dimensions (WxDxH)	335.7 x 257.5 x 93.6 mm
Connectivity technology	Wired
Focus	Manual
Digital zoom	16 x
Focal length range	19.2 - 30.2 mm
Noise level	35 dB
Noise level (economic mode)	31 dB
Dot clock scanning frequency	140 MHz
Lamp type	NSHA
Lamp power	275 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	3000 h
DVI port	No
Composite video in	-
Serial interface type	RS-232
USB 2.0 ports quantity	0
Supported video modes	1080i, 1080p, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	White
AC input voltage	100 - 240 V
Power consumption (standby)	0.7 W
Power consumption (typical)	317 W
Power consumption (PowerSave)	280 W
Cables included	VGA

Weight and Dimensions

Depth	257.5 mm
Width	335.7 mm
Height	93.6 mm
Weight	3500 g
