Data Interfaces
Sample Printouts
For details on the individual information
blocks, see “Configuring Printouts”,
above. For details on configuring the
header lines, refer to the chapter of the
respective application.
“Weighing” application:
If selected, an empty line will be printed.
HEADER LINE1
HEADER LINE2
14.01.2002 09:43
--------------------
G# + 1.402 kg
T + 0.200 kg
N + 1.202 kg
--------------------
Display with ID of weighing platform
--------------------
Ser.no. 80705337
G# + 1.402 kg
T + 0.200 kg
N + 1.202 kg
--------------------
“Counting” application:
The initialization data contains the
reference sample quantity and the
reference sample weight. The results
data contains gross, net and tare
weight and the piece count as a result.
--------------------
nRef 10 pcs
wRef + 0.035 kg
G# + 1.402 kg
T + 0.212 kg
N + 1.190 kg
Qnt 34 pcs
--------------------
“Neutral Measurement” application:
The initialization data block contains the
reference sample quantity and reference
weight. The results block contains gross,
net and tare weight and the piece count
as a result.
--------------------
Ref 2 o
wRef + 1.200 kg
G# + 14.700 kg
T + 0.300 kg
N + 14.400 kg
Qnt 12 o
--------------------
“Weighing in Percent” application:
The initialization data contains the
reference percentage and the reference
sample weight. The results data shows
gross, net and tare weights, as well as the
percentage, which is shown as either the
loss or the residual amount.
Percentage = residue:
--------------------
pRef 100 %
Wxx% + 2.100 kg
G# + 1.859 kg
T + 0.200 kg
N + 1.659 kg
Prc 79 %
--------------------
Percentage = loss:
--------------------
pRef 100 %
Wxx% + 2.100 kg
G# + 0.641 kg
T + 0.200 kg
N + 0.441 kg
D 21 %
--------------------
“Checkweighing” application:
The initialization data contains the
target weight, the min. weight and the
max. weight. The results data always
contains the gross, net and tare weight.
Additional results can be printed in 2
different display types:
– Weight display:
In the OK and nonconforming range,
the deviation from the target weight is
always printed as a percentage and
absolute deviation.
– Relation to target value:
In the OK range, the deviation from the
target weight is printed as a percentage
and absolute deviation.
In the nonconforming range, “HH” is
printed for exceeding the weight and
“LL” for falling below the weight.
OK range in the weight and tolerance
limit display
--------------------
Setp + 1.300 kg
Min + 1.235 kg
Max + 1.365 kg
G# + 1.312 kg
T + 0.000 kg
N + 1.312 kg
Lim + 0.92 %
Diff.W+ 0.012 kg
--------------------
Result outside (over) “OK” range;
“Threshold” printout:
--------------------
Setp + 1.300 kg
Min + 1.235 kg
Max + 1.365 kg
G# + 1.400 kg
T + 0.000 kg
N + 1.400 kg
Stat HH
--------------------
