Installation
When a Combics complete scale is ordered with special equipment, the desired
options come pre-loaded from the factory.
Storage and Shipping Conditions
3
Once the equipment has been removed from the packaging, it may lose accuracy if
subjected to strong vibration.
3
If the load plate is lifted using a vacuum lifting pad, gloves, safety shoes and safety
gear must be worn. Risk of injury! This work may only be carried out by reliable
and authorized personnel.
3
Suspension points are provided for weighing platforms with an overall size of
1 + 1 m or larger.
Do not step under the load during weighing platform/load plate transport or when
lifting. Corresponding accident prevention regulations must be followed. Do not
damage the clamp boxes and load receptors during transport.
– Do not expose the equipment to unnecessarily extreme temperatures, moisture,
shocks, blows or vibration.
– Permissible storage temperature: –10°C to +40°C
Installation location
Avoid adverse infl uences at the place of installation:
– Extreme temperatures (operating temperature: –10°C to +40°C)
– Aggressive chemical vapors
– Extreme moisture (according to IP protection class)
Unpacking
For devices with a platform size of 60 + 80 cm or larger:
t Protective gear must be worn (safety shoes and if required, gloves)
t Always lift on the side walls when lifting or transporting the weighing platform.
t After unpacking the device, check it for any visible damage as a result of rough
handling during shipment.
y If you detect any damage, proceed as directed in the chapter entitled “Care and
Maintenance” under “Safety Inspection."
t Save the original packaging for any future transport.
Unplug all connected cables before packing the equipment.
Check package contents
– Indicator
– Weighing platform
– Operating instructions
– Options (special accessories) as listed on the bill of delivery
Installation
