32 Operating Instructions Combics Indicators
17* Symbols for applications: An active application is identifi ed by a line above and
below the symbol
13
4
5
6
7
8
9
10
11
12131415
16
17
18
19
20
Appl. 1 Appl. 2 Appl. 3
2
.
Application 1*: A “Counting”/ “Neutral Measurement"
B “Weighing in percent"
V “Averaging” (animal weighing)
Application 2*: H “Checkweighing"
W “Classifi cation"
Y “Checkweighing toward zero"
Manually batching to a target value
Application 3*: L “Totalizing"
M “Net total formulation"
18 a The zero-setting symbol is displayed after the active scale or weighing
platform has been zeroed (verifi ed models only)
19 + - Plus or minus sign of the value displayed
20
l
Busy symbol indicates that an internal process is in progress
* = for Combics 2 only
Menu Operating Design
Switching to the Menu
e t Turn on the device.
If it is already on: turn off and then on again.
)
t During the display test, briefl y press the ) key.
y The menu will open. The top most level is always displayed ( “APPLic.”), menu
structure see page 131.
Navigating the Menu
You can navigate the menu using the keys with the white arrows under them.
( Back to the superordinate menu level
k Access the next menu item on the same level.
This continues to page through on the same level.
) Press less than 2 seconds: Select the menu item and save
Press longer than 2 seconds: Exit the menu and switch to weighing mode
p Print the menu settings starting from the current position,
or print Info data
Operating Design
