Operating Instructions Combics Indicators 103
Data Interfaces
Data Input Format
You can connect a computer to your scale to send commands controlling weighing
instrument functions and applications via the interface port.
All commands use the same data input format. They start with the ESC character
(ASCII 27) and end with a carriage return (CR; ASCII 13) and a line feed (LF; ASCII
10). The total length of a command is anywhere from 4 characters (1 command
character between the start and end described above) to max. 7 characters
(4 command characters). This number can also be higher when sending texts.
The commands listed in the following table must each be supplemented with ESC ...
CR LF.
Example: The command character for output is “P” (“output to Port”). To trigger this
command, send the string: “ESC P CR LF”.
Command Meaning
K Weighing mode 1
L Weighing mode 2
M Weighing mode 3
N Weighing mode 4
O Block keys
P Send display value to data interface
Q Output acoustic signal
R Unblock keys
D Tare and zero
(combination tare function)
f3_ Zero (see also the “kZE_” command)
f4_ Tare without zeroing (see also the “kT_” command)
i_ Information about the indicator, example of output: “C2/016202/1”
Explanation: Indicator: Combics 2, software version: 016202, active weighing platform: 1
kF1_ F1: Trigger k key function
kF2_ F2: Trigger c key function (Combics 2 only)
kF3_ F3: Trigger r key function (Combics 2 only)
kF4_ F4: Trigger O key function (Combics 2 only)
kF5_ F5: Trigger w key function (Combics 2 only)
kF6_ F6: Trigger I key function (Combics 2 only)
kF7_ F7: Trigger g key function (Combics 2 only)
kF8_ F8: Trigger h key function (Combics 2 only)
kF9_ F8: Trigger R key function (Combics 2 only)
kF10_ F8: Trigger J key function (Combics 2 only)
kF11_ F8: Trigger K key function (Combics 2 only)
kF12_ F8: Trigger L key function (Combics 2 only)
kCF_ CF: Trigger c key function (Combics 2 only)
kP_ Trigger p key function Print at printer interface
kT_ Trigger T key (tare)
kNW_ Trigger n key function (toggle the weighing platform)
kZE_ Trigger ( key function (zero the instrument)
x1_ Output model designation of active weighing platform, example: “LP6200S-0C"
x2_ Output serial number of active weighing platform, example: “0012345678"
x3_ Output software version of active weighing platform, example: “00-42-04"
x4_ Output software version of indicator, example: “01-62-01"
x9_ Output serial number of indicator, example: “0012345678"
x10_ Output model of indicator, example: “CAW2P4-1500RR-LCE"
z1_ Input: printout header 1
z2_ Input: printout header 2
txx...x_ xx...x: text input, length corresponds to input, for display in the measured value line
The ASCII code for the “underline” character (“_”) is 95.
Format for entering printout header lines: “ESC z x a ... a _ CR LF” with x=1 or 2 and
a ... a: 1 to 20 characters for header x, followed by the underline, CR and LF
characters.
