Page #116 background image
116 Operating Instructions Combics Indicators
Specifi cations
Specifi cations
General Specifications CAW* P | S
Maximum readability 31,250 digits (not in legal metrology)
Accuracy class l (in version ...-.CE)
Number of scale intervals < 3000e “single-range mode” or 2 + 3000e “multiple-range mode” according to
EN 45501
Digital protective interface 2 + 3000e MI, 3 + 3000e MR, 6000e as per EN45501
Data interface Bidirectional RS-232C interface with control output (standard equipment)
Additional data interface Optional
Display 20 mm LCD, 14-segment plus status symbols, backlit
Housing:
Material AISI 304 stainless steel (1.4301)
Dust and water protection acc. to EN60529 CAW1P, CAW2P: IP44 (option IP65)
CAW1S, CAW2S: IP67/69K
CAH1E: IP65 protection, CAH1G: IP67 protection
Temperature range -10°C to +40°C
Power supply 100–240 VAC (–15/+10 %), 50–60 Hz, max. 17 W/23 VA
DC power supply optional 15.5–24 VDC (±10%), max. 12 W
AC power supply optional 13–17 VAC (±10%), 50–60 Hz, max. 12 W
Limitation of emissions Acc. to EN61326+A1 Class B (IEC 61326+A1)
Defi ned immunity to interference Acc. to EN61326+A1, industrial environment (IEC61326+A1)
Electrical safety Acc. to EN61010-1 (IEC 1010-1), EN60950 (IEC 950)
Model-specific Data
Model type: CAW*P...-L CAW*P...-I CAW*P...-BCE CAW*P....-NCE (2 x 3000e)
Readability Readability Readability Weighing range 1 Weighing range 2
Weighing capacity 15000d 30000d 1x3000e Maximum Readability Maximum Readability
capacity capacity
3 kg 0.2 g 0.1 g 1 g 1.5 kg 0.5 g 3 kg 1 g
6 kg 0.5 g 0.2 g 2 g 3 kg 1 g 6 kg 2 g
15 kg 1 g 0.5 g 5 g 6 kg 2 g 15 kg 5 g
30 kg 2 g 1 g 10 g 15 kg 5 g 30 kg 10 g
60 kg 5 g 2 g 20 g 30 kg 10 g 60 kg 20 g
150 kg 10 g 5 g 50 g 60 kg 20 g 150 kg 50 g
300 kg 20 g 10 g 100 g 150 kg 50 g 300 kg 100 g
600 kg 50 g 20 g 200 g 300 kg 100 g 600 kg 200 g
1500 kg 100 g 50 g 500 g 600 kg 200 g 1500 kg 500 g
3000 kg 200 g 100 g 1000 g 1500 kg 500 g 3000 kg 1000 g
