Sartorius Cubis Series Operating Instructions

Getting Started
t Carefully turn the pan support clockwise until the two buttons engage�
The pan support is now attached�
t 2. Insert the shield plate/draft shield�
t 3. Place the weighing pan on the pan support�
y This completes the balance assembly�
Models with a Weighing Range from 20 kg Upwards:
t Place the weighing pan on the balance�
2
3
14 Cubis MSE Operating Instructions

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
