Sartorius Cubis Series Operating Instructions

Care and Maintenance
Cubis MSE Operating Instructions 83
Transporting the Parts (Small Analytical Draft Shield)
t Get the box ready for the individual parts of the balance�
t Get the foam pieces ready�
t Place the balance parts on top of each other
1) Upper draft shield panel
2) Shield plate/draft shield
3) Pan support
t Slide the parts into the foam�
2
1
3

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
