Sartorius Cubis Series Operating Instructions

Care and Maintenance
82 Cubis MSE Operating Instructions
For small weighing pans:
t Place the shield plate into the box�
t Place the pan support and weighing pan into the opening�
t Close the box�
For large weighing pans:
t Insert the following parts into the foam piece:
1) Pan support
2) Shield plate
3) Weighing pan
t Close the box�

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
