Interface Description
This description has been written for users who wish to connect their Sartorius
balance of the MC1 Series to a computer or other peripheral device using
a V24/V28-RS-232C(-S)*)/423 interface.
By using an on-line computer, you can change, activate and monitor the functions
of the balance and the application programs.
This data interface also provides data output port lines for controlling a remote
display unit for over/under checkweighing. In addition, a universal switch
for remote control of various functions can be connected to the data interface port.
If you interface an original Sartorius accessory, such as a Sartorius Data Printer
or a similar unit, with a balance that has the factory-set menu codes, you do not
need to change any settings.
General Specifications
Type of interface Serial point-to-point connector
Operating mode Asynchronous, full duplex
Standard V28, RS-232C
Handshake**) 2-wire interface: via software (XON/XOFF)
4-wire interface: via hardware handshake lines
Clear To Send (CTS) and Data Terminal Ready (DTR)
Transmission rate**) 150; 300; 600; 1,200; 2,400; 4,800; 9,600;
19,200 baud
Character coding 7-bit ASCII
Parity**) Mark***), space***), odd, even
Synchronization 1 start bit; 1 or 2 stop bits**)
Data output format**) 16 or 22 characters
of the balance
Character format**) – 1 start bit
– 7-bit ASCII
– 1 parity bit
– 1 or 2 stop bits
*) = Sartorius pin assignment
**) = can be changed by the user
***) = blocked on verified balances approved as legal measuring instruments
5–1
