Below-Balance Weighing
A port with a below-balance weighing hanger
is available on the bottom of the balance.
To hook a sample on the hanger, open the
below-balance port by removing the two screws from
the bottom of the balance and detaching the cover
plate and gasket.
Now you can attach a sample using a suspension
wire, for example. You also have to install a shield to
protect against drafts.
Fastening an Antitheft
Locking Device
Use the lug (16) located on the rear panel of the
weighing cell to secure the weighing cell with a chain
or a lock at the place of installation.
Important Note for Verified Balances Approved for
Use as Legal Measuring Instruments:
The below-balance weighing port may not
be opened when an approved balance is being
operated as a legal measuring instrument.
1–37
