Use in Combination with Other Programs
Practical Example: Checking Piece Count Symbol displayed: +/–
and “Counting” symbol: P
Application: Checking the piece count of bulk parts of identical weight;
e.g. checking packages of screws where the packages must have
the same weight; checking the fill quantity; sorting.
Menu codes used in the example:
Function Code
Output of application data: on 4 2 1
Output all parameters 7 1 2
Step/Key Display Data Output
Place empty container
on the scale +
31.9 gcs
Press the =/z key 0.0 gcs
Press g/W to select
the reference sample quantity rEF 20 pcs
Place 20 pieces
in the container +
17.5 gcs
Press u/w, activate the
counting application + 20 pcs
The current piece count
and current reference weight nRef + 20 pcs
are output wRef + 0.8750 g
Fill-in required quantity + 200 pcs
Press the g/W key + 200 pcs
Press the z/T key,
activate checkweighing + 200 pcs
The tolerance limit symbol
flashes; the user guide display
shows SEt = target weight
Press the z/T key to store
the weight value + 200 pcs
The user guide display shows
S– – = d – min. weight + 200 pcs
3–26
