Chapter 6 Device Control and Upgrading Updating the Meter Clock
EM13x Series SMART MULTIFUNCTION METER 117
6.2 Updating the Meter Clock
Using the Front Display
Select the RTC entry from the main menu.
To change the time or date:
When in RTC setup menu, applying a LONG PRESS on the
SELECT/ENTER button will display the Time/Date screen while Time
willflash. Another LONG PRESS on SELECT/ENTER button will
flash the actual hour to be changed using SCROLL button
Table 22 describes available options.
Table 22: Clock Setup Options
Display
Label
Parameter
Options
Description
Time
Time
Hh:mm:ss
Hours, minutes and seconds are
separated by ":". The time is displayed as
hh:mm:ss.
Month
name
Date
Mon XX, Year
Month/Day Date and year are separated
by",". Where the first three letters
represent the month, then the day of the
months is represented by two digits and
finally the year presented by 4 digits
Using PAS
Ensure that the On-line button on the PAS toolbar is checked, and
then select RTC from the Monitor menu or click on the Real-Time
Clock button on the PAS toolbar.
The RTC dialog box displays the current PC time and the time in your
meter.
Figure 6-3: Real Time Clock Window
To synchronize the meter clock with the PC clock, click Set.
Reset Exit
SCROLL until
RTC menu
RTC Oct 23,2011
Time 15:03:16
LONG PRESS
RTC Oct 23,2011
Time 15:03:16
SHORT PRESS
Moves to Date
RTC Exit
LONG PRESS
