Satec EM133 User Manual

Appendix F Billing/TOU Profile Log File
166 EM13x Series SMART MULTIFUNCTION METER
Appendix F Billing/TOU Profile Log
File
The following table shows the record structure for the daily billing data
profile log file.
The second column shows data abbreviations used in the PAS data log
reports. Data log file sections are highlighted in bold.
Table 28: Daily Billing/TOU Profile Data Log (Data Log #16)
Field No.
Designation
Description
Energy Register #1
1
REG1
Summary (total) energy reading
2
TRF1
Tariff #1 energy reading
3
TRF2
Tariff #2 energy reading
4
TRF3
Tariff #3 energy reading
5
TRF4
Tariff #4 energy reading
6
TRF5
Tariff #5 energy reading
7
TRF6
Tariff #6 energy reading
8
TRF7
Tariff #7 energy reading
9
TRF8
Tariff #8 energy reading
…
Energy Register #4
1
REG4
Summary (total) energy reading
2
TRF1
Tariff #1 energy reading
3
TRF2
Tariff #2 energy reading
4
TRF3
Tariff #3 energy reading
5
TRF4
Tariff #4 energy reading
6
TRF5
Tariff #5 energy reading
7
TRF6
Tariff #6 energy reading
8
TRF7
Tariff #7 energy reading
9
TRF8
Tariff #8 energy reading
Daily Maximum Demand Register #1
1
REG1 MD
Summary (total) max. demand reading
2
TRF1 MD
Tariff #1 max. demand reading
3
TRF2 MD
Tariff #2 max. demand reading
4
TRF3 MD
Tariff #3 max. demand reading
5
TRF4 MD
Tariff #4 max. demand reading
6
TRF5 MD
Tariff #5 max. demand reading
7
TRF6 MD
Tariff #6 max. demand reading
8
TRF7 MD
Tariff #7 max. demand reading
9
TRF8 MD
Tariff #8 max. demand reading
…
Daily Maximum Demand Register #4
1
REG4 MD
Summary (total) max. demand reading
2
TRF1 MD
Tariff #1 max. demand reading
3
TRF2 MD
Tariff #2 max. demand reading
4
TRF3 MD
Tariff #3 max. demand reading
5
TRF4 MD
Tariff #4 max. demand reading
6
TRF5 MD
Tariff #5 max. demand reading
