Chapter 5 Configuring the EM13X Series General Meter Setup
98 EM13x Series SMART MULTIFUNCTION METER
Table 17: Display Setup Options
Display Label
Parameter
Options
Default
Description
Auto-Scroll
Auto-Scroll
Interval
Disabled,
2-10, 15, 20,
25, 30 seconds
5
Defines the display
scroll interval or
disables auto-scroll
Scroll Seq.
Auto-Scroll
Sequence
1
1-2 to 1-7
1, 5
1, 5-6,
1, 5-7,
1-2, 5-7
1-3, 5-7
1, 6-7
1-2, 6-7
1-3, 6-7
1-4, 6-7
1, 7
1-2, 7
1-3, 7
1-4, 7
1-5, 7
3
3-4
3-5
3-6
3-7
3, 5
3, 5-6
3, 5-7
3, 7
5
5-6
5-7
5,7
1
Selects the display
sequence for auto-
scrolling from 9
data displays (see
Data Displays for
display
enumeration)
Auto-Return
Auto-Return
Disabled,
1-5, 10, 15, 20,
25, 30 min
5
Defines the time
delay before
returning to the
default page
Backlight
Backlight Time
Continuous,
1-10 min
1
Defines the time
while the backlight
is ON
Phase Power
Phase powers
display mode
Enabled
Disabled
Disabled
Disables or enables
phase powers in the
main display
Fundamental Power
Fundamental
component
display mode
Enabled
Disabled
Disabled
Disables or enables
fundamental values
in the main display
Local Time Settings
This setup allows you to specify your time zone, daylight saving time,
and clock synchronization options.
Using the Front Display
Select Local from the main menu. See Viewing and Changing Setup
Options in Chapter 3 for information on configuring parameters via the
front display.
Using PAS
Select General Setup from the Meter Setup menu, and then click on
the Local Settings tab.
Locak Exit
