Appendix D Setpoint Triggers and Actions
154 EM13x Series SMART MULTIFUNCTION METER
Appendix D Setpoint Triggers and
Actions
Table 25: Setpoint Triggers
Designation
Description
NONE
None (condition is not active)
Status Inputs
STAT INP #1 ON
Status input #1 ON
STAT INP #2 ON
Status input #2 ON
STAT INP #3 ON
Status input #3 ON
STAT INP #4 ON
Status input #4 ON
STAT INP #5 ON
Status input #5 ON
STAT INP #6 ON
Status input #6 ON
STAT INP #1 OFF
Status input #1 OFF
STAT INP #2 OFF
Status input #2 OFF
STAT INP #3 OFF
Status input #3 OFF
STAT INP #4 OFF
Status input #4 OFF
STAT INP #5 OFF
Status input #5 OFF
STAT INP #6 OFF
Status input #6 OFF
Relays
RELAY #1 ON
Relay #1 ON
RELAY #2 ON
Relay #2 ON
RELAY #3 ON
Relay #3 ON
RELAY #1 OFF
Relay #1 OFF
RELAY #2 OFF
Relay #2 OFF
RELAY #3 OFF
Relay #3 OFF
Phase Reversal
POS PHASE REVERSAL
Positive phase rotation reversal
NEG PHASE REVERSAL
Negative phase rotation reversal
Low/High 1-Cycle Values on any Phase
HI VOLT RT
1
High voltage
LO VOLT RT
1
Low voltage
HI AMPS RT
High current
LO AMPS RT
Low current
HI V THD
2
High voltage THD
HI I THD
2
High current THD
HI KF RT
High K-Factor
HI I TDD
High current TDD
1-Cycle Auxiliary Values
HI FREQ RT
High frequency
LO FREQ RT
Low frequency
HI V UNB% RT
1
High voltage unbalance
HI I UNB% RT
High current unbalance
1-Sec Phase Values
HI I1 AVR
High I1 current
HI I2 AVR
High I2 current
HI I3 AVR
High I3 current
LO I1 AVR
Low I1 current
LO I2 AVR
Low I2 current
