Satec EM133 User Manual

Appendix D
EM13x Series SMART MULTIFUNCTION METER 155
Designation
Description
LO I3 AVR
Low I3 current
1-Sec Values on any Phase
HI VOLT AVR
1
High voltage
LO VOLT AVR
1
Low voltage
HI AMPS AVR
High current
LO AMPS AVR
Low current
1-Sec Total Values
HI kW IMP AVR
High total kW import
HI kW EXP AVR
High total kW export
HI kvar IMP AVR
High total kvar import
HI kvar EXP AVR
High total kvar export
HI kVA AVR
High total kVA
HI PF LAG AVR
Low total PF Lag
HI PF LEAD AVR
Low total PF Lead
1-Sec Auxiliary Values
HI In AVR
High neutral current
HI FREQ RT
High frequency
LO FREQ RT
Low frequency
Demands
HI V1/12 DMD
1
High V1/V12 Volt demand
HI V2/23 DMD
1
High V2/V23 Volt demand
HI V3/31 DMD
1
High V3/V31 Volt demand
HI I1 DMD
High I1 Ampere demand
HI I2 DMD
High I2 Ampere demand
HI I3 DMD
High I3 Ampere demand
HI kW IMP BD
High block kW import demand
HI kvar IMP BD
High block kvar import demand
HI kVA BD
High block kVA demand
HI kW IMP SD
High sliding window kW import demand
HI kvar IMPSD
High sliding window kvar import demand
HI kVA SD
High sliding window kVA demand
HI kW IMP ACD
High accumulated kW import demand
HI kvar IMP ACD
High accumulated kvar import demand
HI kVA ACD
High accumulated kVA demand
HI kW IMP PRD
High predicted kW import demand
HI kvar IMP PRD
High predicted kvar import demand
HI kVA PRD
High predicted kVA demand
Time and Date Parameters
DAY OF WEEK
Day of week
YEAR
Year
MONTH
Month
DAY OF MONTH
Day of month
HOURS
Hours
MINUTES
Minutes
SECONDS
Seconds
MINUTE INTERVAL
Minute interval: 1-5, 10, 15, 20, 30, 60 min
1
In 4LN3, 3LN3 and 3BLN3 wiring modes, the voltages will be line-
to-neutral; for any other wiring mode, they will be line-to-line
voltages.
