Chapter 3 Using Front Display Data Displays
EM13x Series SMART MULTIFUNCTION METER 67
DISPLAY
Description
Phase Rotation:
Error
Phase rotation order (Error, Positive,
Negative)
DI: 123456
000000
Digital Inputs status
Relays: 123
000
Relays control status
Counter 1:
0
Status/Event Counter 1
Counter 2:
0
Status/Event Counter 2
Counter 3:
0
Status/Event Counter 3
Counter 4:
0
Status/Event Counter 4
Device Info Display
The device info display provides different service information that may
be required for meter identification and inspection, like product and
firmware information, communication settings, and so on, and shows
device diagnostic messages recorded as a result of the meter self-test
diagnostics during start-up and operation.
If there are diagnostic messages, Some of the diagnostics events are
cleared automatically as the event source disappears. See Device
Diagnostic Codes in Appendix G for a full list of diagnostic messages
and their meanings. See Clearing Device Diagnostics for information on
how to clear the device diagnostics from the display and via PAS.
The diagnostic icon can be disabled or enabled via the Display Setup
menu.
DISPLAY
Description
Diagnostics:
8
Power Down message
