Chapter 9 Viewing Files Viewing the Data Log
EM13x Series SMART MULTIFUNCTION METER 141
Figure 9-1: Event Log Window
See Working with Tables for more information on viewing options.
Filtering and Sorting Events
You can use filtering to find and work with a subset of events that
meet the criteria you specify.
Click on the Filter button , or click on the report window with the
right mouse button and select Filter.... Check the causes of events you
want to display, and then click OK. PAS temporary hides rows you do
not want displayed.
To change the default sorting order based on the date and time, click
on the Sortbutton , or click on the report window with the right
mouse button and select Sort..., check the desired sort order, and
then click OK.
9.4 Viewing the Data Log
Data log files can be displayed in a tabular view, one data record per
row, or in a graphical view as a data trend graph.
