Chapter 3 Using Front Display Data Displays
66 EM13x Series SMART MULTIFUNCTION METER
DISPLAY
Description
H1/L3 0 kVA
H1/L3 0 PF
First Harmonic Phase 3 apparent power
and power factor
V1 THD 0 %
I1 THD 0 %
Phase 1 voltage and current THD
V2 THD 0 %
I2 THD 0 %
Phase 2 voltage and current THD
V3 THD 0 %
I3 THD 0 %
Phase 3 voltage and current THD
I1 TDD 0 %
I2 TDD 0 %
Total Demand current Distortion
I3 TDD 0 %
Total Demand current Distortion
V Unb 0 %
I Unb 0 %
Voltage and Current unbalance
Freq 0 Hz
Frequency
V1 Ang 0°
I1 Ang 0°
Voltage and Current Phase 1 angles
(relative to V1 voltage)
V2 Ang 0°
I2 Ang 0°
Voltage and Current Phase 2 angles
(relative to V1 voltage)
V3 Ang 0°
I3 Ang 0°
Voltage and Current Phase 3 angles
(relative to V1 voltage)
