Appendix E
EM13x Series SMART MULTIFUNCTION METER 163
Designation
Description
PF MIN
Total PF
MIN AUX
Minimum 1-Cycle Auxiliary Values
In MIN
In Current
FREQ MIN
Frequency
MAX PHASE
Maximum 1-Cycle Phase Values
V1 MAX
V1/V12 Voltage
1
V2 MAX
V2/V23 Voltage
1
V3 MAX
V3/V31 Voltage
1
I1 MAX
I1 Current
I2 MAX
I2 Current
I3 MAX
I3 Current
MAX TOTAL
Maximum 1-Cycle Total Values
kW MAX
Total kW
kvar MAX
Total kvar
kVA MAX
Total kVA
PF MAX
Total PF
MAX AUX
Maximum 1-Cycle Auxiliary Values
In MAX
In Current
FREQ MAX
Frequency
MAX DMD
Maximum Demands (Power Demands
E, EH
)
V1 DMD MAX
V1/V12 Maximum volt demand
1
V2 DMD MAX
V2/V23 Maximum volt demand
1
V3 DMD MAX
V3/V31 Maximum volt demand
1
I1 DMD MAX
I1 Maximum ampere demand
I2 DMD MAX
I2 Maximum ampere demand
I3 DMD MAX
I3 Maximum ampere demand
kW IMP SD MAX
Maximum kW import sliding window demand
kW EXP SD MAX
Maximum kvar import sliding window demand
kvar IMP SD MAX
Maximum kW export sliding window demand
kvar EXP SD MAX
Maximum kvar export sliding window demand
kVA SD MAX
Maximum kVA sliding window demand
In DMD MAX
In (neutral) current maximum demand
MAX SUMMARY DMD
Billing Summary (Total) Maximum Demands
E, EH
REG1 MD
Summary register #1 maximum demand
REG2 MD
Summary register #2 maximum demand
REG3 MD
Summary register #3 maximum demand
REG4 MD
Summary register #4 maximum demand
AO RAW
Raw Analog Outputs (A/D Units)
AO1
Analog output AO1
AO2
Analog output AO2
AO3
Analog output AO3
AO4
Analog output AO4
TOU PRMS
TOU Parameters
E, EH
ACTIVE TARIFF
Active TOU tariff
ACTIVE PROFILE
Active TOU profile
TOU REG1
Billing TOU Energy Register #1
E, EH
REG1 TRF1
Tariff #1 register
REG1 TRF2
Tariff #2 register
…
…
REG1 TRF8
Tariff #8 register
