Chapter 1 General Information
18 EM13x Series SMART MULTIFUNCTION METER
Parameter
Display
Comm.
Analog
Pulse
Alarm
kvar Maximum Demand Import


kvar Maximum Demand Export

kVA Maximum Demand


Total Energy
Total kWh Import & Export



Total kvarh Import & Export



Total kvarh Net

Total kVAh



Energy per Phase
kWh Import per phase


kvarh Import per phase

kVAh per phase


TOU Registers
4 TOU energy registers (kWh and kvarh
import & export, kVAh, 4 pulse sources)


4 TOU maximum demand registers

8 tariffs, 4 seasons x 4 types of day



Harmonic Measurements
EH
Voltage THD per phase




Current THD per phase




Current TDD per phase




K-factor per phase




Voltage harmonics per phase up to order 40


Current harmonics per phase up to order 40


Voltage harmonic angles up to order 40

Current harmonic angles up to order 40

Fundamental Component
Voltage and Current per phase

kW, PF per phase


kvar, KVA per phase


Total kW, PF


Total kvar, KVA


Min/Max Logging
Min/Max A, V, total kW, kvar, kVA, PF


Min/Max Frequency, Neutral current


Phase Rotation



Voltage and Current Phase Angles


Day and Time


Pulse Counters



Digital Inputs (optional)



Relay Outputs (optional)



Remote Relay Control (optional)

Alarm Triggers/Setpoints


Self-diagnostics


