5. Table data: It can be sent with DATA STORE/RECALL in data maintenance mode.
Setting for table data
:
For table No., set “0” in the beginning of character and then data in 4 bytes. Data in the same
format as fixed data of the printer parameter shall be set for table data. In sequence of table
data 1, 2, and 3, transmit them.
For one data to be transmitted, SOH + H, I, and J as header (as follows) and EOT as trailer
should be put for all data sets (items).
Note: Parenthesis shows the number of byte for each item.
SOH H
STX Table No. (4) Table data (32) ETX
STX Table No. (4) Table data (32) ETX
STX Table No. (4) Table data (32) ETX
EOT
SOH I
STX Table No. (4) Table data (32) ETX
STX Table No. (4) Table data (32) ETX
STX Table No. (4) Table data (32) ETX
EOT
SOH J
STX Table No. (4) Table data (32) ETX
STX Table No. (4) Table data (32) ETX
STX Table No. (4) Table data (32) ETX
EOT
T
a
bl
e
1
:
M
ax.
200
d
a
t
a
Table 2: Max. 200 data
Table 3: Max. 200 data
