SET MACHINE S/N
1. S/N DISPLAY
2. S/N SETTING
SHADING
1. UV SHADING
2. MR SHADING
3. CIS SHADING
4. IR SHADING
S/N Display
You can check the serial no. of the machine.
(In order that S/N is displayed correctly, S/N should be input first in
S/N Setting menu.)
S/N Setting
You can input the serial no. of the machine. It is available up to 20
characters by using Numeric Key.
UP key - Back Space
DOWN key – Used as Right key
In order that a system analyzes Reference Level and
a signal of the machine, the system should know the
full swing of a waveform of a signal.
SENSOR SELECT
1. UV ON
2. MR ON
3. IR ON
4. CF DETAIL OFF
UV, MR, IR: If you want to turn on or off some kind of sensor,
you can do that in this mode.
CF Detail: In case that the machine would reject a Counterfeit
note, you can check the detail reject reason using this menu.
(Turn on this menu and select ‘Reject Reason view’)
Select menu by using UP/DOWN and change ON/OFF by
using START key.
What is Shading?
Sensor Select pass word: *****
ENTER CODE
[ ]
Shading is to make a full swing reference waveform to read the full level of a signal. If the
machine rejects too many notes, the system might not analyze the input of waveform.
It is possible to make a standard waveform for the system.
For more detail information, please refer to the Chapter9.
5. SET MACHINE S/N
6. SHADING
7. SENSOR SELECT
