CURRENCY DISCRIMINATION COUNTER SB-9(2000S) SERVICE MANUAL
- 21 -
SERVICE MENU2
1. SENSOR TEST
2. KEY TEST
3. MOTOR TEST
4. SELECTOR TEST
5. WING SPEED SETTING
8 SERVICE MENU 2
There are ‘Service Menu1’ and ‘Service Men2’ in Service Menu.
‘Service Menu2’ includes the menu to have a test for development or for repair.
8-1. How to enter ‘SERVICE MENU 2’:
8-2. ‘Service Menu2’
Press: 9→MODE→ ***** →DISPLAY
To exit from the current function, press ‘9(menu)’ key.
To move ‘SERVICE MENU1’, press ‘MODE’ key.
< Display of ‘SERVICE MENU2’>
1. SENSOR TEST
------------------------
1) LED TEST
A. HOPPER LED ON
B. HOPPER LED OFF
C. SENSOR LED ON
D. SENSOR LED OFF
2) HOPPER TEST
3) SENSOR LOGIC TEST
4) DOUBLE LOGIC TEST
2. KEY TEST
3. MOTOR TEST
--------------------------
1) DRIVING TEST / 2) DRIVING TEST(P-OCR)
3) FEEDING TEST
4. SELECTOR TEST
--------------------- 1) SELECTOR STACKER / 2) SELECTOR REJECTOR
5. WING SPEED SETTING
-------------
1) WING 1000NPM / 2) WING 1200NPM / 3) WING 1500NPM
