13 Specifications
Item Unit Specification
Size (W x D x H) mm 280 x 269 x 261
Weight (Net) Kg / lbs Approx. 9 / 20
Hopper capacity Notes Max. 500
Stacker capacity Notes Max. 200
Reject pocket capacity
2 RS232C Port, 2 USB Port,
Optional:1 RJ 45 Port
Currencies available 1 (Available up to 7 currencies)
Banknote size range mm W: 100 ~ 185, H: 60 ~ 90
Banknote thickness mm 0.08 ~ 0.12
Counting Speed Notes/min
1000/1200/1500
Operating Mode MIXED/SINGL/FACE/ORIENT/COUNT
Optional: SRL/S-OCR/P-OCR
Preset Batch Number 1 – 200
Counterfeit Detector UV, MG, MR-Array, IR, MDD
Power Requirements 100-240VAC, 50~60Hz
Power Consumption W Standby: 8 , Operation: 55
Ambient Conditions 0~40deg/30~85%RH (Non Condensing)
Notes:
- This specification can be changed without further notice to improve its reliability, function or design.
- The contents of this user's guide can also be changed.
The height dimension does not include the height of the rubber foot.
