CURRENCY DISCRIMINATION COUNTER SB-9(2000S) SERVICE MANUAL
- 34 -
Wait.
Check if the result is ‘OK’ If ‘▼’ is
pressed, shading value is displayed.
To skip, press ‘9’.
▼
▼
This shows WHITE LEVEL.
After checking shading result, press ‘▼’ button.
If you want to move previous MENU, press ‘9’.
IR SHADING
WAIT . . ABOUT 5 SEC
IR SHADING
MIN MAX AVG UNI
IB 0.00 0.74 0.00 –
IW 0.87 1.28 1.00 82%
WB 0.00 0.74 0.00 –
WW 0.88 1.14 0.99 90%
OnTime1: IR_T = 57
OnTime2: WHT T = 63
OK
9 MENU
or
MODE
CODE [ ***** ]
6 4
9 MENU
SERVICE MENU1
1. ERROR STOP CTRL.
2 .SENSOR LEVEL
3. SYSTEM REPORT
4. SET A/S CALL No.
5. SET MACHINE S/N
6. SHADING_______________
7. SENSOR SELECT
SHADING
1. UV SHADING
2. MR SHADING
3. CIS SHADING
4. IR SHADING__________
▼
