CURRENCY DISCRIMINATION COUNTER SB-9(2000S) SERVICE MANUAL
- 42 -
10-6-2. Test Point and adjust Point
Test Point 3 : Reject F
Test Point 4 : Reject R
Low
High
Low
High
Step 1. How to make sheet for adjusting ‘Reject F’
Make a test sheet for adjustment with ‘IR SHADING
(DARK) Sheet’ Provided by SBM.
Cut dotted part as the image on the left side.
Step 2. Place the cut sheet on the REJECT POCKET.
At this time, black side should face upward.
80 ~ 82mm
200 mm
Adjust point: Reject F
Adjust Point: Reject R
