Scaime eNod4-D ETHERNET - Legal for trade

12
SCAIME Manual : NU-eNod4D-ETH-E-0418_216710-E.docx
Metrological specifications on analog output (IO+
version
)
Output voltage range
0-5 or 0-10 V
Output current range
4-20, 0-24 ou 0-20 mA
Max. load on current output
500 Ohm
Outputs resolution
16 bit
Max. linearity error
1 LSB
Total error
+/- 0.07 %FSR
Thermal zero drift typical
+/- 2 ppm/°C
Thermal span drift typical
+/- 3 ppm/°C
Conversion rate
A/D converter rate value Hz
Speed sensor power
-
supply (IO+
version
)
Bridge excitation voltage (V+ …V-)
12.5 +/- 2 V
Bridge excitation current
30 mA
Isolation
1000 V
Speed sensor input (IO+
version
)
IN5 HTL
0…2.5 / 5…30 VDC
IN5 TTL
0…0.5 / 2.4…5 VDC
Isolation
1000 V
3.3 Legal for trade
Characteristics Unit
Accuracy class III or IIII
Maximum number of weighing ranges 1
Maximum number of verification scale divisions
6000
Load cell(s) excitation voltage
5 V
Minimum voltage division per verification scale division
(ΔUmin)
0.5 µV
Minimum voltage of the weighing range
0.5 * n * 10
-3
mV
Maximum voltage of the weighing range 39 mV
Value of factor p
i
0.5
Minimum impedance for the load cell
47 Ohm
Type of load cell(s) connection system 4-wire or 6-wire
Maximum impedance for the load cell 1500 Ohm
Maximal length/section measurement cable
166 m/mm
2
