SCAIME Manual : NU-eNod4D-ETH-E-0418_216710-E.docx
Page 1/3
Feeds sequence
eNod4-D could manage up to 3 feeds: High Feed (HF), Coarse Feed (CF), Fine Feed (FF).
The number and order of used feeds during a cycle is configured by this parameter.
Auto. TARE at Start [Yes], [No] If enable, TARE function is operated after each dosing cycle start
Save result after
STOP
[Yes], [No] If enable, Result saving is also operated after stopping cycle
Page 2/3
Emptying /
reloading
[No], [At End],
[At Start]
define the activation / deactivation and position of emptying
(Reloading in unloading mode) option
Emptying mode [Auto], [Manual]
In filling mode, define the emptying mode: In manual mode,
emptying start after input ‘Manual Emptying’ activation
Emptying end level 0 – 1 000 000
The ‘emptying’ output is disabled if the net value becomes inferior to
this level and if the ‘emptying holding time’ has elapsed.
Reloading Min Level 0 – 1 000 000
Output assigned to the reloading function is activated if the gross
measurement is less than reloading Min Level, until the
measurement become greater than reloading max Level.
Reloading Max
Level
0 – 1 000 000
Page 3/3
Dynamic mode [Yes], [No]
Selecting this option replaces the stability condition for taking tare /
results by averaging measurements over the ‘Calc time Tare/Result’.
Activ FF if OUT- [Yes], [No]
In filling mode, this option automatically restarts the Fine Feed if
dosing result is below low tolerance
Suspend/Resume
cycle allowed
[Yes], [No]
Allows SUSPEND and RESUME cycle. It makes possible to restart a
dosing cycle when starting weight is greater than "empty max.
weight".
13.2.2 Starting conditions setup
Parameter Possible Value Description
Filling mode
Unloading mode
