10 OUTPUTS FUNCTIONING
Each output can work individually in its own logic.
10.1 Outputs assignment:
function Operating mode
transmitter dosing by filling dosing by unloading
none ● ● ●
set point ● ● ●
motion ● ● ●
defective measurement ● ● ●
input image ● ● ●
level on request ● ● ●
cycle in progress ● ●
dosing result available ● ●
fine feed ● ●
coarse feed ● ●
high feed ● ●
emptying ●
reloading ●
out of tolerances ● ●
flow rate failure ● ●
dosing failure ● ●
10.2 General functions:
- none: the output has no function
- set point : the outputs can be assigned to configurable set points (cf. §8) Output 1 is assigned to set point 1 , output 2
to set point 2, output 3 to set point 3 and output 4 to set point 4.
Set points are characterized by a high and a low value.
Their operating mode is either operating in hysteresis or operating in window.
