Scaime eNod4-D ETHERNET - Optional Communication and Filters; Bluetooth Communication (Optional)

25
SCAIME Manual : NU-eNod4D-ETH-E-0418_216710-E.docx
5.6 Bluetooth
®
Communication (Optional)
Information related to the radio emission are the followings:
Information Radio
Wireless communication Bluetooth® Low Energy 4.2
Max. RF output power -16.9 dBm
Frequencies range 2.4 – 2.4835 GHz
Activation or deactivation of Bluetooth® fonctionnality is done by dipswitch #4 on SW3.
Dipswitch
Bluetooth®
1 2 3 4
X X X ON Active
X X X OFF Inactive
A blue light on front side indicates the status of the Bluetooth® communication.
Blue light
Bluetooth® COM Status
Off Inactive
Fast blinking Initialization
Slow blinking Ready for pairing with mobile device
Steady On Active and paired
The communication through Bluetooth® allows, using the dedicated mobile app eNodApp, to visualize the different
weighing values, the Inputs / Output states and the applicative cycle states from an Android device. Moreover, it
allows to perform some actions such as:
- Perform a Zero or Tare,
- Calibrate a sensor,
- Parametrize Inputs/Outputs,
- Set filtering parameters,
- Read/Clear DSD records,
- Set application parameters,
- And more…
The theoretical range of the Bluetooth® communication is about 10 meters without obstacles.
eNodApp application is available in English and French version and can be downloaded from the Google Play Store.
