Scaime eNod4-D ETHERNET - Dosing Timing Setup

76
SCAIME Manual : NU-eNod4D-ETH-E-0418_216710-E.docx
 Filling mode
Min. empty weight
± 500 000
Allow empty packing presence verification at the start of cycle: Min
empty weight < Gross measurement <Max empty weight.
If Min empty weight = Max empty weight = 0: No verification
Max. empty weight
Automatic start [Yes], [No]
Filling cycle starts automatically when the gross weight is between
the 'Min. empty weight' and 'Max. empty weight'.
 Unloading mode
Residual weight 0 – 1 000 000
eNod4-D refuse ‘start cycle’ and reports a dosing error if gross
measurement < (target weight + residual weight).
13.2.3 Dosing Timing Setup
Parameter Possible Value Description
Timing parameters
