Scaime eNod4-D ETHERNET - Dosing Tolerance control; Dosing Target values

79
SCAIME Manual : NU-eNod4D-ETH-E-0418_216710-E.docx
13.2.6 Dosing Tolerance control
Parameter Possible Value Description
Tolerance control parameters
Tolerance – and + 0 – 65565
Define the acceptable range for dosing results. An output assigned
to the ‘out of tolerances’ is set active if the dosing result is not
within the range.
13.2.7 Dosing Target values
 Target adjustment screen can be displayed from the Setup menu or directly from the main screen
with key
 According to the Feed sequence setting, the following screen are displayed:
