2 ENOD4 PRODUCT RANGE
2.1 General presentation
eNod4 is a high speed digital process transmitter with programmable functions and powerful signal processing
capabilities. eNod4 offers operating modes for advanced process control both static and dynamic.
Quick and accurate:
 Analog to digital conversion rate up to 1920 meas/s with maximum scaled resolution of ±500 000 points.
 Digital filtering and measurement scaling.
 Measurement transmission up to 1 000 meas/s.
Easy to integrate into automated system:
 USB, RS485 and CAN communication interfaces supporting ModBus RTU, CANopen® and PROFIBUS-DPV1
(depending on version) communication protocols.
 Digital Inputs/Outputs for process control.
 Setting of node number by rotary switches and communication baud rate by dip switches.
 Integrated selectable network termination resistors.
 Wiring by plug-in terminal blocs.
2.2 Versions
2.2.1 Communication protocol versions
 Strain gauges load-cell conditioner with CANopen® and ModBus RTU communication.
 Strain gauges load-cell conditioner with Profibus DP-V1 and ModBus RTU communication.
 Strain gauges load-cell conditioner with Modbus TCP and ModBus RTU communication.
 Strain gauges load-cell conditioner with EtherNet/IP and ModBus RTU communication.
 Strain gauges load-cell conditioner with Profinet IO and ModBus RTU communication.
 Strain gauges load-cell conditioner with EtherCAT and ModBus RTU communication.
EDS, GSD, ESI and GSDML configuration files for above protocols can be downloaded from our web site:
http://www.scaime.com
2.2.2 IO+ version
In conjunction with all communication protocol versions, eNod4 can supports an opto-insulated board fitted with:
 2 additional digital inputs and 1 speed sensor dedicated input.
 0-5V or 0-10V analog output voltage.
 4-20mA, 0-24mA, 0-20mA or 4-20mA with alarm at 3.6mA analog output current.
2.2.3 Bluetooth
®
version
In conjunction with all communication protocol versions and IO+ version, eNod4 can supports a communication board
that allows to exchange information via Bluetooth®.
Radio information
Wireless communication Bluetooth® Low Energy 4.2
Max. RF output power -16.9 dBm
Frequency range 2.4 – 2.4835 GHz
