ScanMegInc.     ModuleSIM‐P

UserManual  26   Version1.3

Thescanaccuracyhasaninfluenceonthescanrate.Themorepreciseitscansthemorecellshaveto
becheckedforthefinalresult.In Coarsemode thescanrateissetto1500sc ans/sec..InStandard
mode,thescanrateis800scans/sec.andinFinemode,the
scanrateisreducedto400scans/sec..In
HSmode,thescanrateis1400scans/sec.Inthismodewescanthesamenumberofcellsasinthe
coarsemodebutwiththeaccuracyoftheequivalentmode.Thefieldofviewisreducedbutthescan
rateis 
optimum.WhentheStandardHSortheFineHSmodearechosen,onlyasectionofthefield
ofviewisfunctioningtorunwithHighSpeedscanrateattheStandardortheFineresolution.InHS
mode,onlyhalfofthefieldofviewisfunctioningforthe
StandardHSmodeandonly¼ofthefieldof
viewfortheFineHSmode.Thescanratesare:

Mode
ScansRate Fieldofview(in.)
scans/second P150 P225 P300 P450 P600
Coarse
1500
6 9 12 18 24
Standard
800
6 9 12 18 24
Fine
400
6 9 12 18 24
Standard HS
1400
3 4.5 6 9 12
Fine HS
1400
1.5 2.25 3 4.5 6


Mode
ScansRate Fieldofview(mm)
scans/second P150 P225 P300 P450 P600
Coarse
1500
150 225 300 450 600
Standard
800
150 225 300 450 600
Fine
400
150 225 300 450 600
Standard HS
1400
75 112.5 150 225 300
Fine HS
1400
37.5 56.25 75 112.5 150

WhenyouselectoneoftheseHSscanmodes,youhavetoselectthepositionofthescanzone.After
validatingthe mode,youneedtoalsoselectthepositionofthezonebymovingitupordow n(F1or
F2button).Whenthescanzoneislocatedat
thecorrectposition,justpushtheEnterbutton.Ifthe
zoneisalreadyatthecorrectlocation,justpushtheEnterbuttonwithoutmovingthezone.

