ThescanningzonewillbedisplayedontheLEDstatusofeachcell.Whenthismodeischosen,allnon‐
scanLEDsare displayed like cancelled LEDs (note:they are not really cancelled, as one canseeas 
soonasonecomesbacktoascanningmodewithouttheHSfeature).
Howeverpreviouslycancelled
LEDs,ifany,staycanceledregardlessofthedisplay.
ThescanaccuracyselectionhasaneffectontheavailableBaudratefortheseriallinkandviceversa.
IfoneoftheCoarse,StandardHSorFineHSisselected,onlyBaudrate38400Bdsandslower
willbe
availableontheBaudRateselection parametermenu.Conversely,ifa57,600or115200Bds rateis 
selectedwhentheyareavailableontheBaudrateparametermenu,thecoarseaccuracy,theStandard
HSaccuracy andtheFineHSaccuracywill notbeavailableinthismenu.Makesure
thatyouselect
therightBaudratetoavoidsomelimitationonthescanaccuracymode.Insummary,ifyouchoose
Baudrateof38400Bdsorlower,allofthescanaccuracymodeswillbeavailable.












ScanaccuracyWarning
IFYOUTRYTOSCANWITHACCURACYINFINE MODE AND THEDISTANCEOFTHEEMITTERORRECEIVED IS LESSTHAN6
FEET(2M), YOUNEEDTOSET THEINTENSITYOFTHE EMITTERTOTHEMINIMUM.IFNOT, THEINTENSITYISTOOHIGH
MAKINGABLUREFFECT.THISEFFECTRESULTSINALOSSINACCURACY.THESERIALLINKISALSOLIMITEDTOAMAXIMUM
OF38400BDSIFTHECOARSE,STANDARDHSORFINEHSMODEISSELECTED.
