Scheppach SG5200D User Manual

www.scheppach.com
GB
|
23
Drive motor type 4-stroke air-cooled
Displacement 418 cm³
Max. power (engine) 5.7 kW
Fuel Diesel
Tank contents 16 l
Engine oil 1.65 l
Engine oil type 15W40
Consumption at ⅔ load approx. 1.43 l/h
Weight 145.9 kg
Performance class G1
Quality class B
Max. altitude (above mean
sea level)
1000 m
Technical changes reserved!
Operating mode S1 (continuous operation)
The machine may be operated continuously with the
specied power.
Operating mode S2 (short-term operation)
The machine may only be operated at maximum power
for a brief time. Then, the machine must be brought to
a standstill for a period of time so that it is not allowed
to heat up.
Noise & vibration
m Warning: Noise can have serious e󰀨ects on your
health. If the machine noise exceeds 85 dB (A), please
wear suitable hearing protection.
Noise data
Sound power level L
WA
96.2 dB(A) (EN ISO 3744)
Sound pressure level L
pA
77 dB(A) (EN ISO 11201)
Uncertainty K
wa/pA
2.1 dB(A)
7. Unpacking
Open the packaging and carefully remove the device.
Remove the packaging material, as well as the packag-
ing and transport safety devices (if present).
Check whether the scope of delivery is complete.
Check the device and accessory parts for transport
damage. In the event of complaints the carrier must be in-
formed immediately. Later claims will not be recognised.
Burns:
Touching the exhaust pipe
Leave the device to cool down
Fire - explosion:
Diesel is ammable
Smoking is prohibited when refuelling and working
Warning! This power tool generates an electromag-
netic eld during operation. This eld can impair active
or passive medical implants under certain conditions.
In order to prevent the risk of serious or deadly injuries,
we recommend that persons with medical implants
consult with their physician and the manufacturer of
the medical implant prior to operating the power tool.
Residual risks
The machine has been built according to the state-of-
the-art and the recognised technical safety require-
ments. However, individual residual risks can arise
during operation.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the “Safety infor-
mation” and the “Proper use” together with the oper-
ating manual as a whole are observed.
• Keep your hands away from the work area, when the
machine is in operation.
6. Technical data
Generator AVR
Protection category IP23M
Continuous output P
nenn
(S1)
3000 W at 230V~
4200 W at 400V 3~
Power P
max
(S2/5min)
3300W at 230V~
5000 W at 400V 3~
Rated battery voltage U
nenn
230 V~
400 V 3~
12V DC.
Rated current I
nenn
230V - 13A
400V - 7.6A
12V - 8.3A
Frequency F
nenn
50 Hz

Scheppach SG5200D Specifications

General

Fuel type	Diesel
Rated power	3000 W
Engine power	7.7 hp
Maximum power	5000 W
Rated voltage	230 V
Ignition system	Electronic
Rated frequency	50 Hz
Fuel consumption	1.43 l/h
Fuel tank capacity	16 L
Engine displacement	418 cm³
Engine number of strokes	3
Castor wheels	Yes
Product color	Black, Blue
Inverter technology	-

Weight and Dimensions

Depth	920 mm
Width	520 mm
Height	750 mm
Weight	148000 g
Package depth	710 mm
Package width	935 mm
Package height	535 mm
Package weight	160000 g
