Schindler 3100/3300/6300 J 43402603 / 01 110/269
Copyright © 2017 INVENTIO AG
9
0x37 55 Internal software
An unknown event set the door drive
to a state where the determinate
behavior of the system cannot be
guaranteed anymore
Restart door drive by plugging off
POWT and CANT (DOOR) on OKR
10
0x39 57 Sensor position
The DDE-VD-35 encoder has
encountered an error
 Reset the DDE-VD35 by shortly
plugging off POWT and CANT
(DOOR) on OKR
 Run autosetup
11
0x3A 58 CAN overrun Check CAN cable2. Check CAN
Communication
12 0x3D 61 CAN Tx COB Id_Collision
13 0x3E 62 CAN PDO length too short
14 0x3F 63 CAN bus Off
15 0x40 64 CAN Rx queue overflow
16 0x41 65 CAN Tx queue overflow
17
0x43 67 Position following an obstacle
that slows down or stops the door
(only possible if force limit detraction
KSKB/KOKB) is disabled
Check for obstacles or blocking
situations, challenge the application
setting of KOKB, KSKB
18
0x43 67 Position following too high
acceleration/deacceleration
Reduce parameter 39_speed_close
and 40_speed open
Code Car Door Message
0369
DOOR MAX OPENING FORCE EXCEEDED
The maximum door opening force was exceeded
ID Possible Causes Actions to be taken
1
The door opening is obstructed by an
obstacle
Check the doorway and remove any
obstacles or dirt
Code Door Contact Message
0370
DOOR CONTACT END CLOSING CLOSED BRIDGED
The contact end door closing-closed bridged (KET-S2) of the door is not open
when the door reaches the opened position
ID Possible Causes Actions to be taken
1
The wiring of the contact KET-S2 is
not correct
Check the wiring according to the
schematics. If found wrong, correct
2 The contact KET-S2 is overbridged Remove jumper
Code Door Locking Message
0371
DOOR LOCKING UNLOCKING OBSTRUCTED
The clutch locking respectively unlocking motion is obstructed
ID Possible Causes Actions to be taken
