Lock assembly drawing index
Schlage • L-Series service manual • 17
LM9300 Multipoint functions
ANSI/ICC 500 for tornadoes
FEMA 320 and FEMA 361 certified for tornadoes
Keyed Locks
Trim
assembly
page no.
Lock
assembly
page no.
Lock case
page no.
SCHLAGE Description
LM9350 Oce and inner entry lock function multipoint
Latchbolt is retracted by knob/lever from either side unless outside is made
inoperative by key outside or inside thumbturn. When outside is locked, latchbolt
is retracted by key and knob/lever outside or by knob/lever inside. Outside knob/
lever remains locked until thumbturn is returned to vertical position or unlocked
by key. Auxiliary latch deadlocks latchbolt when door is closed. Inside knob/lever
is always free for immediate egress. For use with Multipoint lock system only.
28 62 L283-316
LMV9350 Oce and inner entry lock function multipoint with Vandlgard�
Latchbolt is retracted by knob/lever from either side unless outside is made
inoperative by key outside or inside thumbturn. When outside is locked, latchbolt
is retracted by key and knob/lever outside or by knob/lever inside. Outside knob/
lever remains locked until thumbturn is returned to vertical position or unlocked
by key. Auxiliary latch deadlocks latchbolt when door is closed. Inside knob/lever
is always free for immediate egress. Vandlgard function allows exterior lever to
rotate freely down while remaining securely locked. For use with Multipoint lock
system only.
28 63 L283-317
LM9370 Classroom lock function multipoint
Latchbolt is retracted by knob/lever from either side unless outside is locked by
key. Outside is unlocked by key. When outside is locked, latchbolt is retracted by
key and knob/lever outside or by knob/lever inside. Inside knob/lever is always
free for immediate egress. Auxiliary latch deadlocks latchbolt when door is
closed. For use with Multipoint lock system only.
30 62 L283-316
LMV9370 Classroom lock function multipoint with Vandlgard
�
Latchbolt is retracted by knob/lever from either side unless outside is locked by
key. Outside is unlocked by key. When outside is locked, latchbolt is retracted by
key and knob/lever outside or by knob/lever inside. Inside knob/lever is always
free for immediate egress. Auxiliary latch deadlocks latchbolt when door is
closed. Vandlgard function allows exterior lever to rotate freely down while
remaining securely locked. For use with Multipoint lock system only.
30 63 L283-317
LM9371 Classroom security lock* function Multipoint
Latchbolt is retracted by knob/lever from either side unless locked by key from
either side. When outside is locked, latchbolt is retracted by key and knob/lever
outside or knob/lever inside. Inside knob/lever is always free for immediate
egress. Auxiliary latch deadlocks latchbolt when door is closed. Available with
lock indicator on inside per XL11-986. For use with Multipoint lock system only.
29 62 L283-316
LMV9371 Classroom Security Lock* Function Multipoint with Vandlgard�
Latchbolt is retracted by knob/lever from either side unless locked by key from
either side. When outside is locked, latchbolt is retracted by key and knob/lever
outside or knob/lever inside. Inside knob/lever is always free for immediate
egress. Auxiliary latch deadlocks latchbolt when door is closed. Available with
lock indicator on inside per XL11-986. Vandlgard function allows exterior lever to
rotate freely down while remaining securely locked. For use with Multipoint lock
system only.
29 63 L283-317
LM9380 Storeroom lock function multipoint
Latchbolt is retracted by outside knob/lever aer key is inserted and rotated
280°, or anytime by inside knob/lever. Outside knob/lever is always inoperative.
Auxiliary latch deadlocks latchbolt when door is closed. Inside knob/lever is
always free for immediate egress. For use with Multipoint lock system only.
30 70 L283-316
LMV9380 Storeroom lock function multipoint with Vandlgard�
Latchbolt is retracted by outside knob/lever aer key is inserted and rotated
280°, or anytime by inside knob/lever. Outside knob/lever is always inoperative.
Auxiliary latch deadlocks latchbolt when door is closed. Inside knob/lever is
always free for immediate egress. Vandlgard function allows exterior lever to
rotate freely down while remaining securely locked. For use with Multipoint lock
system only.
30 71 L283-317
* Caution: Double cylinder locks on residences–or on any door in any structure which are used for egress–are a life safety hazard in times of
emergency, and their use is not recommended. Installation should be in accordance with existing codes only.
