Installation and operating instructions
24 Vers. 1.0 2024_03
3.4 Circuit structure, wiring
Thanks to the flexibility of the system, the connection of the luminaires is arbitrary, but it is
advisable to always indicate the final route in the implementation documentation. To reduce
the overall length of the cable, junction box stops are allowed.
In the table in 3.2, the maximum cable lengths for the circuits are specified for 1.5 mm² or
2.5 mm² cross section. Twisted, sleeved or solid conductors may be used.
Luminaire connection example
