Assembly
24
09.00 | PGN-plus | Assembly and Operating Manual | en | 389296
Item Mounting PGN-plus
40 50 64 80 100 125
1 Thread in the main air
connections
M3 M5 M5 M5 G1/8 G1/8
Max. depth of
engagement from
locating surface [mm]
4 6 6 6 7 7
2 Thread in the air purge
connection
M3 M5 M5 M5 M5 M5
Max. depth of
engagement from
locating surface [mm]
4 5 6 6 6 6
Item Mounting PGN-plus
160 200 240 300 380
1 Thread in the main air
connections
G1/8 G1/8 G1/8 G1/4 G1/4
Max. depth of engagement
from locating surface [mm]
7 7 8 12 12
2 Thread in the air purge
connection
M5 M5 M5 M5 M5
Max. depth of engagement
from locating surface [mm]
6 6 6 6 8
5.3 Mounting the sensor
NOTE
Observe the assembly and operating manual of the sensor for
mounting and connecting.
The product is prepared for the use of sensors.
• For the exact type designations of suitable sensors, please see
catalog datasheet and Overview of sensors [
}
25].
• For technical data for the suitable sensors, see assembly and
operating manual and catalog datasheet.
– The assembly and operating manual and catalog datasheet
are included in the scope of delivery for the sensors and are
available at schunk.com.
• Information on handling sensors is available at schunk.com or
from SCHUNK contact persons.
