Assembly
34
09.00 | PGN-plus | Assembly and Operating Manual | en | 389296
Alternatively for size 40 - 160, except 50:
Setting the sensor in "Standard mode"
Ø Turn the sensor 1 (1) into the groove (2).
OR: Slide the sensor 1 (1) into the groove (2) until the sensor 1
(1) stops at the T-nut (3).
Ø Secure the sensor 1 (1) using the set-screw (4).
Tightening torque: 10Ncm
Ø Adjust sensor 1 (1), see sensor assembly and operating manual.
Ø Repeat steps for sensor 2.
NOTE
If there is no T-nut available, slide the sensor according to
dimension I1 into the groove (2),
Setting dimensions for magnetic switches [
}
27].
