Assembly
36
09.00 | PGN-plus | Assembly and Operating Manual | en | 389296
Dimensions I1
Size l1* [mm] Size l1* [mm]
40 15.4 100 28.7
40 AS 20.0 100 AS 22
40 IS 20.0 100 IS 55.6
40-KVZ 28.2 100-KVZ 55.2
40 AS-KVZ / IS-KVZ 37.2 100 AS-KVZ / IS-KVZ 81.2
50 At stop 125 23.0
50 AS 23.0 125 AS 59.6
50 IS At stop 125 IS 56.9
50-KVZ At stop 125-KVZ 55.5
50 AS-KVZ / IS-KVZ At stop 125 AS-KVZ / IS-KVZ 85.5
64 22.4 160 35.5
64 AS 19.2 160 AS 76.0
64 IS 39.5 160 IS 75.5
64-KVZ 41.4 160-KVZ 71.9
64 AS-KVZ / IS-KVZ 59.4 160 AS-KVZ / IS-KVZ 111.9
80 26.5
80 AS 22.0
80 IS 44.5
80-KVZ 49.0
80 AS-KVZ / IS-KVZ 67.0
* Dimension l1 Bottom edge of the product to front edge of the
