Assembly
38
09.00 | PGN-plus | Assembly and Operating Manual | en | 389296
Dimensions I1
Size l1* [mm] Size l1* [mm]
40 13 100 28.7
40 AS 22.4 100 AS 22
40 IS 21.7 100 IS 55.6
40-KVZ 25.8 100-KVZ 55.2
40 AS-KVZ / IS-KVZ 34.8 100 AS-KVZ / IS-KVZ 81.2
64 22.4 125 23.0
64 AS 19.2 125 AS 59.6
64 IS 39.5 125 IS 56.9
64-KVZ 41.4 125-KVZ 55.5
64 AS-KVZ / IS-KVZ 59.4 125 AS-KVZ / IS-KVZ 85.5
80 26.5 160 34.4
80 AS 22.0 160 AS 71.7
80 IS 44.5 160 IS 71.7
80-KVZ 49.0 160-KVZ 71.9
80 AS-KVZ / IS-KVZ 67.0 160 AS-KVZ / IS-KVZ 111.9
* Dimension l1 Bottom edge of the product to front edge of the
sensor
